ZT-10DL, 10 Ton Telescoping Bottle Jack ( 2 Stage )
$390.34
Out of stock
SKU
83-10DL
Overview
The Zinko ZT-10DL is a high-stroke, 10-ton dual-stage telescoping hydraulic bottle jack built for heavy commercial fleet service and industrial rigging. This 25 lb unit maximizes vertical extension by pairing a 10.30" ram stroke with a 7.63" starting clearance to reach a 21.73" maximum extended height. Built with an internal safety overload valve, a wide structural base, and thermal-resistant internals rated for -40°F to 140°F climates, it functions reliably in upright pushing or horizontal pushing applications.
Special Features:
- Safety valve designed to protect the hydraulic system from overload damage
- Welded steel construction for added strength while preventing oil leakage
- Adaptable to a variety of environments between -40°F ~ 140°F
- Models with additional screw extension offer increased use of the stroke
- Can be used in both vertical and horizontal positions with lifting capacity
Country of Origin: Taiwan
| Capacity (Tons) | 10 |
|---|---|
| Minimum Height (in) | 7.63 |
| Maximum Heights (in) | 21.73 |
| Ram Lift (in) | 14.10 |
| Screw Extension (in) | 3.80 |
| Base Area (in) | 7.08 X 6.88 |
| Weight (lbs) | 22.000000 |
| Pump Direction | Vertical |
