ZN-60, 60 Ton Standard Bottle Jack
$1,049.71
In stock
SKU
81-60
Overview
The Zinko ZN-60 is an ultra-high-capacity, 60-ton hydraulic bottle jack engineered exclusively for heavy structural lifting, foundation leveling, and large-scale plant rigging. Built to withstand severe high-pressure environments, this 83 lb jack incorporates an advanced base-forging method and high-strength electric-welded seams to resist metal fatigue. It delivers an absolute lifting force of 120,000 lbs across a 6.69" hydraulic ram stroke, working within a 12.00" to 18.70" operational envelope.
Special Features:
- Welded steel construction throughout reduces metal fatigue allowing for a longer life
- Unique base forging method increases resistance to high pressure and gives a degree of durability and performance not found in any other comparable product
- ZN models are usable in multiple positions: upright, angled, or horizontal
- Special grade steel results in high durability and helps to prevent rust
- Casting, cylinder, and base are jointed by an electric welding method for high strength and to prevent leaking
- Needle valve allows you to control the lowering of the ram
- Heat-treated extension screws provide a low pickup height adjustment and maximum lift height
- Safety valve device protects the hydraulic system from overload damage
Country of Origin: Japan
| Capacity (Tons) | 60 |
|---|---|
| Minimum Height (in) | 12.00 |
| Maximum Heights (in) | 18.70 |
| Ram Lift (in) | 6.69 |
| Screw Extension (in) | --- |
| Base Area (in) | 9.33 x 7.40 |
| Weight (lbs) | 83.000000 |
