ZAP-40, 40 in³ Air Pump
$448.97
In stock
SKU
22-040
Overview
The Zinko ZAP-40 is a compact, 10,000 PSI air-over-hydraulic pump engineered to power hydraulic tools and low-displacement cylinders. Operating on a 40–140 PSI input air range, it features an anodized aluminum housing, a 37 cubic inch usable fluid reservoir, and a 360° swivel hose connector for unrestricted positioning. An integrated "air-thrust" design provides rapid initial slack take-up, making this 15 lb unit the ideal power source for Zinko ZHC series toe jacks equipped with pneumatic air ports.
Special Offer!
Ut enim ad minim veniam quis nostrud laboris nisi 20% off. Sed aliquip do eiusmod tempor: XYZ20
Special Features:
- Convenient 360° swivel hose connector for better hose control and increase the flexibility for work in any position.
- Exclusive "air-thrust" design rapidly takes up slack, putting the cylinder rod or tool in work position within seconds.
- Heavy-duty anodized aluminum housing is extremely durable.
- Portable to any job site equipped with compressed air. Takes the place of manual pumps reducing operator fatigue and increasing productivity.
- Compact, lightweight design for easy handling and storage.
Country of Origin: Taiwan
| Oil Capacity (in³) | 37 |
|---|---|
| Pressure Rating (psi) | 10,000 |
| Output Flow Rate - No Load (in³/min) | 215 |
| Output Flow Rate - Load (in³/min) | 12 |
| Air Pressure Range (psi) | 40-140 |
| Air Consumption (scfm) | 9 |
| Sound Rate (dba) | 85 |
| Port Size (NPT) | 3/8" |
| Weight (lbs) | 15.000000 |
